Changeover switch 3pos 40A

Lovato Electric GA series 3-phase switch and disconnector with a rated current of 40 A. The device is designed for reliable disconnection and isolation of electrical circuits in electrical installations and industrial equipment. Can be mounted directly on a plate or on a standard 35 mm DIN rail. The robust construction and high reliability ensure a long service life even in demanding conditions.

Technical data:

Product code: GA040A

Series: GA

Number of poles: 3 (three-phase)

Rated current (Ith, in free air): 40 A

Rated current AC21A / AC22A / AC23A (400-690 V): 40 A / 25 A

Rated insulation voltage (Ui): 1000 V AC

Impulse voltage withstand (Uimp): 8 kV

Short-time withstand current (Icw 1s): 0.8 kA

Maximum short-circuit current withstand (Icm): 10 kA

Mounting method: Screw-mounted on a plate or 35 mm DIN rail (IEC/EN 60715)

Terminal type: Screw terminals, M4 screws

Screw torque: 1.8 – 2.0 Nm

Wire cross-section: 0.75 – 16 mm²

Mechanical life: 100,000 cycles

Electrical life (AC21A): 100,000 cycles

Operating temperature: –25 °C … +55 °C

Protection class: IP20 (front)

Weight: 146g

Certificates: IEC/EN 60947-3, IEC/EN 60947-1, UL 60947-4-1, CSA C22.2 n° 60947-4-1

EAN code: 8013975177600
