Screw connector Al/Cu 6–25 mm² 1 kV

Ouneva screw-type splicing sleeve is suitable for joining aluminum and copper conductors in cable connections up to 1 kV. It is used in situations where cable or conductor ends need to be connected to each other correctly, securely, and reliably.

The 6–25 mm² splicing sleeve is suitable for small to medium cross-section Al/Cu conductors. The screw connection solution is a convenient choice when you do not want to use a crimping tool. The connection is made with an Allen key, and the sleeve has 4 screws.

Technical specifications
EAN: 6410052012823
Manufacturer: Ouneva
Product code: VB04-0015
Product type: screw-type splicing sleeve / Al-Cu splicing sleeve
Conductor cross-section: Cu 6–25 mm² / Al 10–25 mm²
Voltage: up to 1 kV
Conductor material: aluminum / copper
Conductor shape: round or sector-shaped
Surface treatment: tinned
Number of screws: 4
Connection method: screw connection
Application: splicing Al and Cu conductors in low-voltage installations and cable connections

Suitable for, for example:
splicing aluminum and copper conductors;
connecting low-voltage cables;
use in panels and distribution boards;
cable connections and splice joints;
repair and maintenance work;
locations where you do not want to use a crimp-type splicing sleeve;
connections where a screw-type 4-screw splicing sleeve is required.

We recommend also looking at: heat-shrink tubing, insulation accessories, cables, Allen keys, wire strippers, and installation accessories.

Not sure if this splicing sleeve is suitable? Write or call us — we will help you choose the right solution.
