Circuit breaker 1P C32 6kA

The MAXGE EPB-63M-1C-32 is a single-pole miniature circuit breaker with a C-type tripping characteristic, designed for the protection of distribution, equipment, and high-load single-phase circuits. The C-type characteristic is suitable for circuits where higher inrush currents may occur, such as smaller motors, transformers, or technical equipment.

Technical specifications

Manufacturer: MAXGE
Series/model: EPB-63M
Product code: EPB-63M-1C-32
Product type: miniature circuit breaker / MCB
Number of poles: 1P
Number of protected poles: 1
Rated current: 32 A
Tripping characteristic: C
Breaking capacity: 6 kA
Rated voltage: up to 400 V AC
Frequency: 50/60 Hz
Rated insulation voltage Ui: 500 V
Rated impulse withstand voltage Uimp: 4 kV
Energy limiting class: 3
Voltage type: AC
Protection degree: IP20
Mounting: DIN rail
Width: 1 module / 17.8 mm
Connection terminals: up to 25/35 mm², depending on conductor type
Tightening torque: 2–3.5 Nm
Compatible with accessories: yes
Application: protection of distribution, equipment, and high-load single-phase circuits in distribution boards

Suitable for, for example

Suitable for installation in a distribution board for the protection of single-phase high-load consumers, technical equipment, smaller motors, or distribution circuits requiring a 32A C-characteristic circuit breaker.
