Circuit breaker 1P C25 6kA

The Gewiss GW92009 is a 1-pole C-curve miniature circuit breaker with a rated current of 25 A. It is suitable for protecting electrical circuits against overload and short circuits in residential, commercial, and technical installations.

The C-curve is suitable for circuits where higher than normal inrush currents may occur, such as with appliances, small motors, or technical equipment. The circuit breaker is designed for mounting on a DIN rail in an electrical distribution board.

Technical specifications

Manufacturer: Gewiss
Series/model: MT 60 / 90 MCB
Product code: GW92009
EAN: 8011564375925
Individual product EAN/GTIN: 8011564057067
Product type: miniature circuit breaker / MCB
Number of poles: 1P
Rated current: 25 A
Characteristic: C
Breaking capacity according to EN 60898: 6 kA
Number of modules: 1 module
Rated voltage: 230/400 V AC
Voltage type: AC
Frequency: 50/60 Hz
Installation: DIN rail
Application: protection of electrical circuits against overload and short circuit
Standard: EN 60898-1
Package quantity: 1 pc

Suitable for, for example

Protecting appliance circuits
Protecting high-load 1-phase circuits
Protecting small motors or technical equipment
Electrical switchboards in residential, commercial, and industrial installations
Situations requiring 1-phase 25 A circuit protection with C-curve

We recommend also looking at: electrical distribution boards, DIN rail accessories, busbars, connection terminals, and other Gewiss miniature circuit breakers.

Not sure if this circuit breaker is suitable for your distribution board or solution? Write or call us — we will help you choose the right solution.
