Circuit breaker 1P C2 6kA

The MAXGE EPB-63M-1C-2 is a single-pole C-curve miniature circuit breaker with a low rated current for the protection of control, automation, signal, and auxiliary circuits. Suitable for use in electrical distribution boards for overload and short-circuit protection.

Technical specifications

Manufacturer: MAXGE
Series/model: EPB-63M
Product code: EPB-63M-1C-2
Product type: miniature circuit breaker / MCB
Number of poles: 1P
Number of protected poles: 1
Rated current: 2 A
Tripping characteristic: C
Breaking capacity: 6 kA
Rated voltage: 230/400 V / up to 400 V AC
Frequency: 50/60 Hz
Rated insulation voltage Ui: 500 V
Rated impulse withstand voltage Uimp: 4 kV
Energy limiting class: 3
Voltage type: AC
Degree of protection: IP20
Mounting: DIN rail
Width: 1 module / 17.8 mm
Dimensions: 17.8 × 72 × 81.5 mm
Weight: 0.125 kg
Auxiliary accessories compatible: yes
Application: protection of control, automation, signal and auxiliary circuits in electrical distribution boards

Suitable for, for example

Suitable for use in electrical boards for protecting low-load control and auxiliary circuits, such as automation, signal circuits, relays, transformers, or supply circuits for smaller devices.
